A diode laser uses semiconductor technology that produces coherent projection of light in the visible to infrared range. It uses a light beam with a narrow spectrum to target specific chromophores in the skin. Compared to other laser systems such as the Ruby and Alexandrite, the 808nm diode laser wavelength offers the deepest penetration levels and superior melanin absorption. These unique characteristics make the diode laser the most suitable technology for laser hair removal, enabling safe and effective treatment of all skin and hair types, in all body areas.
Diode lasers use the principle of selective photothermolysis (abbreviated SPTL) to target specific chromophores in the skin, usually melanin or blood. The lasers damage the chromophores by selectively heating them while leaving surrounding tissue unharmed. When treating unwanted hair, for example, the melanin in the hair follicles is targeted and damaged which results in the disruption of hair growth and regeneration. A diode laser can be complemented by cooling technology, or other pain reducing methods which improve treatment efficacy and patient comfort.
Optimal wavelength of 808 nm（755nm, 940nm, 1064nm for customization）
High peak power of Machine 2400 W
Fluence of up to 200 J/cm2
Ergonomic Applicator With Seven Changeable Spot Sizes
Seven Tips: 12*12mm, 12*20mm, 12*28mm, 12*34mm, 4*4mm, Φ8mm, Φ 10mm
Each tip fits seamlessly onto the one lightweight applicator, eliminating the need for multiple applicators or bulky, expensive replacement parts for spot size flexibility
Ergonomic applicator designed for comfort providing optimal operator usage.
Return on Investment
The diode laser hair removal device containing features that enables a higher return on ownership, such as a lower investment cost, quicker treatments, no disposables, and IoT capability.
Integrated IOT Technology
1. Equipped with an advanced connectivity module, enable “Internet of Things” (IoT) capability for enhanced business operations through data analysis & reporting.
2. IoT monitors device usage and performance allowing insights into utilization and ROI for the provider.
3. Revolutionary Real-Time Cooling System: Monitors applicator temperature 1,000 times per second
4. Consistent temperature delivery provides exceptional patient comfort, safety, and satisfaction for all skin types.
Versatile With Two Modes of Operation
PULSE mode through higher energy delivery at shorter pulse durations, results in enhanced patient outcomes requiring less treatment sessions.
SLIDE mode enhances patient comfort through continuous motion over the treatment area delivering shorter pulses and higher repetition. Lower intensity and superior cooling result in a quicker, more comfortable treatment.
Tech Specs
Input Voltage – 100-230 VAC, less than 12A, 50-60 Hz, Single Phase
Wavelength – 800 ± 15 nm
Max. Peak Power – 2400 watts
Spot Sizes – 12*12mm, 12*20mm, 12*28mm, 12*34mm, 4*4mm
Fluence Range – 1-200 J/cm2
Pulse Repetition Rate – Up to 10 Hz
Pulse Duration – 5 -170 m s e c
Dimensions -55 cm x 65 cm x 110 cm
Weight – 55 kg
